YYW-6000A Dynamic Balancing Machine Used for Motor Rotor Fan Impeller Balance

YYW-6000A balancing machine suitable for wind turbine impellers, water pump impellers and other rotating diameter and damping of large work-pieces or rotor surface irregularities or work-pieces with a knife seat

Whatsapp: +86-18253885137

Tel / Wechat: 0086-18253885137

Email: franksong@beacon-machine.com

inquiry

Introduction

YYW-6000A Dynamic Balancing Machine Used for Motor Rotor Fan Impeller Balance

Equipment Model:YYW-6000A

Maximum mass of work-piece kg:3000
Minimum mass of work-piece kg:100
Maximum diameter of work-piece on bed guideway surface mm φ2400
Bed length mm:4000*1100*260
pendulum structure:Modular construction, roller H-type support
Support shaft diameter mm:φ40-180，φ180-300
Balance speed r/min:110-1170
Minimum Residual Unevenness Measure:≤1 g.mm/kg
reduction in imbalance%:≥90%
Motor power:11KW
Speed control method:Frequency control + 4-speed mechanical gears
transmission method:Universal joints (two sets for 300nm and 2500nm)
Overall size (L*W*H):4200*1100*2300
